C64K 4-Axle Standard Gauge Bogie Wagon

RailMac C64K 4-Axle Standard Gauge Bogie Wagon

The C64K 4-Axle Standard Gauge Bogie Wagon is a versatile open-top rail vehicle designed for efficient bulk transportation of coal, ore, grain, and other granular or bulk materials. With a loading capacity of 61 t and a spacious loading volume of 73.3 m³, it balances high payload efficiency with operational flexibility. Its lightweight tare weight of 23 t and 21 t/axle load rating ensure compliance with standard railway infrastructure requirements while minimizing energy consumption.
As part of SinoMac, RailMac provides full life‑cycle services for the C64K 4-Axle Standard Gauge Bogie Wagon, including design, system supply, installation, commissioning, after‑sales training, spare parts supply, troubleshooting and overhaul support, ensuring stable and efficient performance throughout its service life.

Advantages of C64K 4-Axle Standard Gauge Bogie Wagon

A 23 t lightweight tare weight paired with a 61 t loading capacity delivers an excellent payload-to-weight ratio, reducing per-tonne transportation costs and energy consumption while maximizing single-trip cargo throughput.
The 73.3 m³ loading volume provides ample space for low-density bulk materials such as grain or coal, avoiding wasted capacity and ensuring efficient utilization of each wagon.
A maximum full-load speed of 120 km/h shortens transit times, supporting timely delivery of time-sensitive bulk cargo and improving overall supply chain efficiency.
The 1435 mm standard gauge and 145 m minimum negotiable curve radius enable seamless integration into most global railway networks, allowing flexible deployment across diverse track layouts and operational scenarios.

Technical Specifications

Trains Model:	C64K 4-Axle Standard Gauge Bogie Wagon
Loading Capacity:	61 t
Gauge:	1435 mm
Axle Load:	21 t/axle
Max Speed (Full Load):	120 km/h
Loading Volume:	73.3 m³

coming soon

Model	Loading Capacity	Gauge	Axle Load	Max Speed	Loading Volume
C64K 4-Axle Standard Gauge Bogie Wagon	61 t	1435 mm	21 t/axle	120 km/h	73.3 m³
C70 4-Axle General-Purpose Open Wagon	70 t	1435 mm	23 t/axle	120 km/h	77 m³
C70E 4-Axle Open Goods Wagon	70 t	1435 mm	23 t/axle	120 km/h	80.8 m³
C80B 4-Axle Open Wagon Specialized for Coal	80 t	1435 mm	27 t/axle	100 km/h	92 m³
C80E 4-Axle General Open Wagon	80 t	1435 mm	27 t/axle	100 km/h	92 m³
——END——

Main Parameters
Loading capacity	61 t	Tare weight	23 t
Axle load	21 t/axle	Loading Volume	73.3 m³
Overall length	13438 mm	Overall width	3242 mm
Overall height	3139 mm	Gauge	1435 mm
Max speed (full load)	120 km/h	Minimum radius of curvature negotiable	145 m
——END——

Q1: Do you have the design capability to provide customized railway vehicles?

A: Yes, we have a professional technical team and are familiar with international railway standards such as UIC, AAR, EN, etc. We are able to provide railway equipment according to customer requirements.

Q2: The Chinese railway gauge is 1435 mm, but the railway gauge in our country is 1000 mm. Will this be a problem for you?

A: Of course not, we are able to design railway vehicles with different gauges, such as 1435 mm, 1000 mm, 1067 mm, 1520 mm or other required railway gauges.

Q3: Compared with your competitors, why should I choose you?

A: Tieke Railway was transformed from China Railway Freight Car Factory in 2016. The company has more than 10 years of experience in railway vehicle manufacturing; now, as Tieke Railway is a private company with modern market management strategies, our services are flexible, considerate, and the cost is more controllable.

Q4: What should I provide to get your quotation?

A: You can send an inquiry with detailed drawings, product photos, detailed technical parameters or demand description. Complete demand input is very important for us to provide you with an accurate quotation.
